Scenario
Light Color
Remarks
eLight fault
The strip light flashes in red if eLight
fails to communicate with the
ECC800-Pro.
-
Table 8-62 eLight system technical specifications
Item
Specifications
eLight power

Rated input voltage: 220 V AC/230 V AC/240 V AC

Frequency: 50/60 Hz

Output: ≥ 93 W, 24 V DC

Certification: CE
eLight actuator

Rated input voltage: 24 V DC

Two output channels. The I output is connected to the
RGBW flexible strip light, and supplies different voltages
depending on host instructions so that the light can be in
different colors. The II output supplies a fixed voltage of 24
V DC.

Modbus communications protocol, RS485 interface, two
RJ45 ports

Certification: CE
eLight strip light

Rated input voltage: 24 V DC

Light type: RGBW LED strip light, in different colors
depending on instructions

Power: RGB fully on under the maximum working
condition, power P ≤ 12 W/m

Installation mode: buckled in a sheet metal light slot

Certifications: CE and CCC
Protection level
≥ IP20
Operating environment

Operating temperature range: 4–40°C

Humidity range: 5%–95%, non-condensing
8.3.12 (Optional) iBattery
The iBattery consists of the iBOX and iBAT.
The iBOX is a battery information collection module. It collects battery status data from a
group of downstream iBATs through wireless communication, and sends the data to the
upstream management unit through a COM or PoE port.
The iBAT is a battery monitoring module that supports 12 V power input and monitors the
voltages, internal resistances, and pole temperatures of batteries.
