Huawei FusionModule2000 - Multi-Functional Sensor

FusionModule2000 Smart Modular Data Center
Product Description
8 Intelligent Module Management System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
171
Pin
Description
Pin6
V-
Pin7
Reserved
Table 8-37 Temperature and humidity sensor specifications
Item
Specifications
Temperature measuring range
–20°C to +80°C
Temperature accuracy
±0.5°C (25°C)
≤±1°C (full measuring range)
Operating temperature
–20°C to +80°C
Operating voltage
9–16 V DC
Storage temperature
–40°C to +80°C
Output
RS485
8.3.7.5 Multi-Functional Sensor
A multi-functional sensor integrates the temperature and humidity (T/H) sensor, smoke sensor
and infrared detection. The multi-functional sensor can connect to the ECC800-Pro over FE
or wireless communication.
The infrared detection function is enabled only when the intelligent lighting function is enabled.
