Huawei FusionModule2000 Product Description

FusionModule2000 Smart Modular Data Center
Product Description
8 Intelligent Module Management System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
172
Figure 8-29 Multi-functional sensor
(1) Address DIP switch
(2) BLINK button
(3) TEST button
(4) RF_Z indicator
(5) RUN indicator
(6) ALM indicator
Specifications
Table 8-38 Multi-functional sensor technical specifications
Item
Specifications
Temperature
monitoring
–40°C to 70°C. Precision ≤ ±0.5 °C (0-50 °C).
Humidity
monitoring
0 to 100% RH. Precision ≤ ±5% RH (25°C, 20%–80% RH).
Smoke
monitoring
Complies with Ul217. The smoke sensor generates an alarm when
testing 3.2% weak dust for each foot.
POE port
One POE port that complies with IEEE802.3 at.
RS485 port
Reserves one RS485 port.
DI input
One DI input port, 12 V DC power input.
BLINK button
Wireless communication:

If the sensor is not connected to the network, after you hold down
the button for 2s to 3s, the sensor connects to the network in RF_Z
mode.

If the sensor is connected to network, after you hold down the button
for 2s to 3s, the RUN indicator blinks.

Hold down the button for more than 6s to clear network parameters.
Test button
Supports the smoke sensor test.
