8.3.8.5 Card Reader with a Keypad
Figure 8-34 Card reader with a keypad
Table 8-49 Specifications of a card reader with a keypad
Item
Specifications
Dimensions (L x W x H)
114 mm x 63 mm x 25 mm
Operating voltage
Operating voltage range: 10.8–13.2 V DC; rated voltage:
12 V DC
Operating current
Static standby current 80 mA, dynamic operating current
(card swiping, key pressing) 150 mA, minimum input
current 12 V DC/300 mA
Communications mode
Wiegand communications port
