FusionModule2000 Smart Modular Data Center
Product Description
8 Intelligent Module Management System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
181
Item
Specifications
Communications mode
RS485 and Wiegand communications ports
Table 8-48 Access control device operating status
Item
New Version
Standby
LED indicator
The indicator is steady blue.
Fingerprint reader
The indicator is off.
Unauthorized fingerprint
collection
LED indicator
The indicator blinks blue,
red, blue, red, and blue in
order.
Fingerprint reader
The indicator turns on
(white).
Buzzer sounds
The buzzer sounds three.
Authorized fingerprint
collection
LED indicator
The indicator blinks blue,
red, and blue in order.
Fingerprint reader
The indicator turns on
(white).
Buzzer sounds
The buzzer sounds once.
Card swiping
LED indicator
The indicator blinks blue,
red, and blue in order.
Buzzer sounds
The buzzer sounds once.
