Silk
Screen
Description
Status
Initial Status
STATUS_
0V
SWITCH
STATUS_
BP
Port for monitoring the
bypass input circuit breaker

Connected: circuit
breaker ON

Disconnected:
circuit breaker
OFF
Connected
SWITCH
STATUS_
0V
Port for signal ground
SPD
Port for monitoring the
input AC surge protective
device (SPD)

Connected: SPD
enabled

Disconnected:
SPD disabled
Connected
0V
Port for signal ground

The dry contact interface card takes effect only after it is set on the monitoring system. Set the
unused dry contact signal to the unused status.

Set the EPO port to NO or NC as required.

When multiple UPSs are paralleled, all dry contact signals to be used need to connect to each UPS.

Single cables require dual-insulated twisted cables. If the length of a power cable is within 25–50 m,
its cross-sectional area must be 0.5 mm
2
to 1.5 mm
2
.
5.2.2.4.4 Monitoring Interface Card

Only once being set will dry contact signals take effect. Set unused dry contact signals to
the unused state on the LCD.

In a parallel system, ensure that used dry contacts properly connect to each UPS.
The monitoring interface card provides external ports as well as monitoring and control
functions for the MDU. The ports include the ambient temperature and humidity sensor port,
FE port, battery temperature monitoring port, and network management port. MDU functions
include monitoring of the UPS, allowing users to set parameters, command delivery,
information reports, and UPS key information and parameters displayed on the LCD.
