FusionModule2000 Smart Modular Data Center
Product Description
7 Temperature Control System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
115

The controller provides abundant external ports such as RS485 ports, CAN ports, FE
ports, and USB ports that are protected by a security mechanism.

The smart cooling product supports communications protocols such as Modbus RTU,
Modbus TCP, and SNMP, facilitating connection to the network management system.

The controller intelligently identifies abnormal parameter settings (incorrect commands)
and rejects them automatically.

If the indoor temperature fluctuates beyond the normal range, an audible and visible
alarm signal is sent automatically.
7.3.4 Physical Ports
Table 7-12 shows the physical ports on the NetCol5000-A in-row smart cooling product.
Table 7-12 Physical port description
Item
Specifications
Refrigerant liquid pipe
Copper pipe; outer diameter: 5/8 in.; pressure resistance ≥ 4.5
MPa; welded
Refrigerant gas pipe
Copper pipe; outer diameter: 3/4 in.; pressure resistance ≥ 4.5
MPa; welded
Humidifier water inlet
pipe
Reserved port: BSPP 1/2 in.; thread connection
Top drainpipe
Reserved port: BSPP 1/2 in.; thread connection
Bottom drainpipe
Reserved port: copper pipe with an outer diameter of 5/8 in.;
you are advised to use a hose with an inner diameter of 14 mm
for connection.
7.3.5 Technical Specifications
Table 7-13 and Table 7-14 respectively show the main technical specifications of the
NetCol5000-A in-row smart cooling product.
Table 7-13 General specifications
Item
Specifications
Cooling mode
Air cooled
Refrigerant
R410A
Cooling capacity
35 kW
Air volume
6000 m
3
/h
Air supply mode
Horizontal air supply
Certification
REACH, RoHS, CE, WEEE, China Energy Conservation
Certification, and IEC
Cooling capacity test conditions: dry bulb temperature at air return vent: 37°C; relative
