Table 6-1 Network cabinet technical specifications
Item
Technical Specifications
External dimensions (H x
W x D)

2000 mm x 600 mm x 1100 mm (with castors)

2000 mm x 600 mm x 1200 mm (with castors)

2000 mm x 800 mm x 1100 mm (with castors)

2000 mm x 800 mm x 1200 mm (with castors)

2000 mm x 600 mm x 1200 mm (without castors)

2200 mm x 600 mm x 1200 mm (without castors)

2200 mm x 800 mm x 1200 mm (without castors)
Color
Black (PANTONE426C/RAL9005)
Material
High-intensity class A carbon cold rolled steel plate and
zinc-coated steel plate
Air channel
Front and rear air channels
Installation space

A 2000 mm high cabinet provides 42 U available space.

A 2200 mm high cabinet provides 47 U available space.

The distance between the front and rear mounting bars can
be adjusted by the step of 25 mm. Positions behind the
cabinet are reserved for installing two rPDUs.
Installation mode
Installed on a concrete floor, a base, or an ESD floor
Door opening mode
The front door is a single door, and the rear door is a double
one.
Weight of an empty
cabinet
The weight of an empty
cabinet includes the
weight of the front and
rear doors.

2000 mm x 600 mm x 1200 mm: 128 kg

2000 mm x 800 mm x 1200 mm: 153 kg

2200 mm x 600 mm x 1200 mm: 137 kg

2200 mm x 800 mm x 1200 mm: 164 kg

2000 mm x 600 mm x 1100 mm: 110 kg

2000 mm x 800 mm x 1100 mm: 135 kg
Protection level
IP20
6.1.2 IT Cabinet
An IT cabinet used in the smart module complies with the International Electrotechnical
Commission (IEC) 60297-1 standard and provides stable installation space for servers,
thereby ensuring safe operation of servers.
The cabinet dimensions are unified, and both front and rear air channels are designed.
