FusionModule2000 Smart Modular Data Center
Product Description
3 Product Description
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
5
Table 3-2 Smart module installation modes
Scenario
Illustration
Without a
raised floor
NOTE
Typically,
overhead
cabling and
overhead
piping
With a raised
floor
NOTE
Typically,
overhead
cabling and
underfloor/over
head piping,
bottom cabling
and
underfloor/over
head piping
3.2 Single-Row 1200 mm Wide Aisle Containment
The single-row 1200 mm wide aisle containment can be a cold or hot aisle containment that
involves the following components: IT cabinet, network cabinet, PDF, smart cooling product,
battery cabinet, skylight, end door, and cable trough. A cold aisle containment is used as an
example.
