Figure 6-11 Installation positions for cable management devices
(1) Cable rack
(2) Cable ring
(3) Cable tray
The installation positions for cable management devices are for reference only. Determine the
installation positions based on the actual situation.
6.1.7 (Optional) Adjustable Base
An adjustable base for the smart module can be 300 mm, 600 mm, or 800 mm wide. The
minimum adjustment range is 1 mm.
