FusionModule2000 Smart Modular Data Center
Product Description
6 Cabinet Aisle System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
89
Table 6-7 Base specifications
Type
Dimensions
600 mm wide smart
cooling product, PDF, IT
cabinet, battery cabinet, or
network cabinet base
Height (adjustable): 270 mm ≤ H ≤ 410 mm; depth
(adjustable): 1000 mm, 1100 mm, or 1200 mm
Height (adjustable): 410 mm ≤ H ≤ 700 mm; depth
(adjustable): 1000 mm, 1100 mm, or 1200 mm
300 mm wide smart
cooling product base
Height (adjustable): 270 mm ≤ H ≤ 410 mm; depth
(adjustable): 1000 mm, 1100 mm, or 1200 mm
Height (adjustable): 410 mm ≤ H ≤ 700 mm; depth
(adjustable): 1000 mm, 1100 mm, or 1200 mm
800 mm wide IT or
network cabinet base
Height (adjustable): 270 mm ≤ H ≤ 410 mm; depth
(adjustable): 1000 mm, 1100 mm, or 1200 mm
Height (adjustable): 410 mm ≤ H ≤ 700 mm; depth
(adjustable): 1000 mm, 1100 mm, or 1200 mm
6.2 Aisle and Mechanical Parts
6.2.1 Skylight
Skylights are used for sealing an aisle containment. Skylights are classified as control
skylights, rotating skylights, and flat skylights.
Table 6-8 Skylight technical specifications
Item
Dimensions (H x W x D)
Applicable Cabinet
Dimensions (Width)
Control skylight
341 mm x 605 mm x 1334 mm
600 mm
341 mm x 805 mm x 1334 mm
800 mm
300 mm wide flat
skylight
341 mm x 305 mm x 1334 mm
300 mm
600 mm wide flat or
rotating skylight
341 mm x 605 mm x 1334 mm
600 mm
800 mm wide flat or
rotating skylight
341 mm x 805 mm x 1334 mm
800 mm
