FusionModule2000 Smart Modular Data Center
Product Description
Copyright © Huawei Technologies Co., Ltd.
Figure 6-12 Control skylight
(1) Skylight connective plate
(2) Control skylight panel
(3) Cable separation panel
Control skylights are installed on both ends of an aisle and used to install monitoring components
such as the camera, multi-functional sensor, and smoke detector.
If the smart module is longer than 7 m, add one control skylight in the middle of the smart module
for installing a multi-functional sensor or smoke detector.
Figure 6-13 Flat or rotating skylight
(1) Magnetic lock fixing base
(3) Skylight connective plate
A rotating skylight is designed with an eccentric structure. When the trigger is activated, a rotating
skylight falls under gravity. When a magnetic lock is triggered, the rotating skylight falls under
gravity.
The rotating skylight requires a magnetic lock but the flat skylight does not.
