FusionModule2000 Smart Modular Data Center
Product Description
8 Intelligent Module Management System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
165
Specifications
Table 8-29 Skylight actuator technical specifications
Item
Specifications
Power input

DC input: Terminal, with input voltage of 36 V DC – 60 V DC

POE input: One POE port that complies with IEEE802.3 at.
POE port
FE communication with the rate of 10/100M
Wireless
communication
One wireless port that complies with IEEE802.15.4, mutual backup
with FE communication
AI/DI port
Two AI/DI ports for detecting fire extinguishing linkage signals;
smoke detection signals also supported
DO output
One 12 V DC power output for controlling the skylight magnetic lock;
driving six skylight magnetic locks simultaneously
DI input
One DI input port for connecting to the window open button
BLINK button

Hold down the button for less than 1 second to start blinking.

Hold down the button for 1–5 seconds to search for a network and
start networking.

Hold down the button for more than 10 seconds to clear network
parameters.
Address DIP
switch
4-pin address DIP switch
E-label
Supported
Indicators
Table 8-30 Skylight actuator indicator description
Indicator
Color
Name
Status
Description
Power
Green
Power input
status indicator
Steady on
The power input is normal.
Off
There is no power input.
RUN
Green
Operating
status indicator
Off
The power is abnormal or the
board program is loading.
Blinking at
long intervals
The skylight actuator
successfully registers with the
ECC800-Pro and the software
runs properly (the indicator
blinks at 0.5 Hz, on for 1s and
then off for 1s).
Blinking at
short intervals
The communication fails or the
skylight actuator fails to register
