Figure 8-40 IPC6325 camera
Table 8-51 IPC6325 camera technical specifications
Item
Specifications
Image sensor
1/2.7" two-megapixel progressive scan CMOS
Lowest illuminance

Color: 0.01 lux (F1.4, AGC ON)

Black and white: 0.004 lux (F1.4, AGC ON)
0 lux (infrared enabled)
Wide dynamic range
120 dB
Focal length
2.8–12 mm manual zoom, 4.3x optical zoom
Video coding format
H.265/H.264/MJPEG
Maximum resolution
1920x1080
Power supply
PoE (802.3at/af), 24 V AC±25%, 24 V DC±25%, 12 V
DC±25% (polarity-insensitive DC power supply),
applicable to DC/AC adapter and PoE hot backup
Protection level
IP66; complying with IEC 60529
Vandal-proof class
IK10; complying with IEC 62262
