FusionModule2000 Smart Modular Data Center
Product Description
5 Power Supply and Distribution System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
75
Table 5-48 Battery cabinet technical specifications
Item
Technical Specifications
External dimensions (H x
W x D)

Basic dimensions: 2000 mm x 600 mm x 1100 mm

Dimensions after expansion: 2200 mm x 600 mm x 1100
mm (with the top frame)

Basic dimensions: 2000 mm x 600 mm x 1200 mm

Dimensions after expansion: 2200 mm x 600 mm x 1200
mm (with the top frame)
Color
Black (PANTONE426C/RAL9005)
Material
High-intensity class A carbon cold rolled steel plate and
zinc-coated steel plate
Air channel
Front and rear air channels
Installation space
42 U
Installation mode
Installed on a concrete floor or ESD floor
Door opening mode
The front door is a single door, and the rear door is a double
one.
Weight
128 kg (excluding batteries)
Protection level
IP20
Shoto and Enersys batteries are supported.
Table 5-49 Maximum number of batteries inside a battery cabinet
Battery Specifications
Maximum Number of Batteries
Inside a Battery Cabinet
26 Ah
40
40 Ah
65 Ah
20
100 Ah
Table 5-50 Configuration scenarios (for both the main and auxiliary battery cabinets)
Battery
Specifications
Layer (from
Top to
Bottom)
Number of Batteries
-
-
40
38
36
34
32
