Figure 7-104 Installing the bae plate of the FlexIO card
Step 5 Thread the guide pins on the mainboard through the holes in the FlexIO card, and
push the FlexIO card horizontally into the chassis to have the FlexIO card
connected to the connector on the mainboard. See (1) in Figure 7-105.
RH2288H V3 Server
User Guide 7 Replacing Parts
Issue 46 (2022-12-28) Copyright © Huawei Technologies Co., Ltd. 243
