Huawei RH2288H V3 User Manual

Figure 3-2 Direction of heat dissipation
3.2.2 Temperature and Humidity Requirements
To ensure continued safe and reliable equipment operating, install or position the
system in a well-ventilated, climate-controlled environment.
● Use temperature control devices all year long in any climates.
● In dry areas, use
humidiers to ensure ambient humidity.
● In humid areas, use dehumidiers.
Table 3-1 Temperature and humidity requirements in the equipment room
Item
Description
Temperature 5°C to 40°C (41°F to 104°F)
Relative humidity (RH,
non-condensing)
8% to 90%
3.2.3 Cabinet Requirements
The cabinet must meet the following requirements:
● A standard 19-inch cabinet with a depth of more than 1000 mm (39.37 in.).
● Complies with International Electrotechnical Commission 297 (IEC 297).
RH2288H V3 Server
User Guide 3 Installing and Removing the RH2288H V3
Issue 46 (2022-12-28) Copyright © Huawei Technologies Co., Ltd. 82

Huawei RH2288H V3 Specifications

General

Form Factor	2U Rack
Processor	Intel Xeon E5-2600 v3/v4 series
Memory	Up to 1.5 TB, 24 DDR4 DIMM slots
Storage	Supports up to 12 x 3.5-inch or 25 x 2.5-inch SAS/SATA HDDs/SSDs
RAID Support	RAID 0, 1, 10, 5, 50
Network	2 or 4 x GE ports
Power Supply	2 x hot-swappable PSUs
Management	iBMC (Intelligent Baseboard Management Controller)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
