(3) I/O signal assignment
The controller's I/O port signal varies depending on the parameter No.25 setting.
[Refer to 3.8 Remote I/O Mode]
Set the parameter No.25 of MCON
Positioning mode Teaching mode 256-point mode
0 1 2
Category
Port
No.
Symbol
Signal Name
Symbol Signal Name Symbol Signal Name
0 PC1 PC1 PC1
1 PC2 PC2 PC2
2 PC4 PC4 PC4
3 PC8 PC8 PC8
4 PC16 PC16 PC16
5 PC32
Specified position No.
PC32
Specified position No.
PC32
6 – MODE
Teaching mode
command
PC64
7 – JISL
Jog/inching switching
PC128
Specified position No.
8 –
Unavailable
JOG+
+Jog
–
Unavailable
9 BKRL
Brake release
JOG-
-Jog
BKRL
Brake release
10 –
Unavailable
–
Unavailable
–
Unavailable
11 HOME
Home return
HOME
Home return
HOME
Home return
12 *STP
Pause
*STP
Pause
*STP
Pause
13 CSTR
Positioning start
CSTR/
PWRT
Positioning start/
Position data import
command
CSTR
Positioning start
14 RES
Reset
RES
Reset
RES
Reset
PLC output
→
MCON input
15 SON
Servo ON command
SON
Servo ON command
SON
Servo ON command
0 PM1 PM1 PM1
1 PM2 PM2 PM2
2 PM4 PM4 PM4
3 PM8 PM8 PM8
4 PM16 PM16 PM16
5 PM32
Completed position No.
PM32
Completed position No.
PM32
6 MOVE
Moving signal
MOVE
Moving signal
PM64
7 ZONE1
ZONE1
MODES
Teaching mode signal
PM128
Completed position
No.
8
(Note 1)
PZONE/
ZONE2
Position zone/
Zone 2
PZONE/
ZONE1
Position zone/
Zone 1
PZONE/
ZONE1
Position zone/
Zone 1
9 –
Unavailable
–
Unavailable
–
Unavailable
10 HEND
Home return completion
HEND
Home return
completion
HEND
Home return
completion
11 PEND
Positioning completion
signal
PEND/
WEND
Positioning completion
signal/Position data
import complete
PEND
Positioning
completion signal
12 SV
Operation preparation
end
SV
Operation preparation
completion
SV
Operation preparation
end
13 *EMGS
Emergency stop
*EMGS
Emergency stop
*EMGS
Emergency stop
14 *ALM
Alarm
*ALM
Alarm
*ALM
Alarm
MCON output
→
PLC input
15
LOAD
/TRQS
*ALML
Torque check
(Note 2)
/
Light malfunction output
*ALML
Light malfunction output
LOAD
/TRQS
*ALML
Torque check
(Note 2)
/
Light malfunction
output
Note 1 It is available to change in Parameter No. 149 Zone Output Switchover.
Note 2 It is available to change in Parameter No. 156 Torque Inspection / Light Malfunction Output Select for the pulse
motor driver.
It is the light malfunction output for the servo motor driver / brushless DC motor driver.
(Note) “*” in codes above shows the signal of the active low. (A signal of active low is a signal that the input signal is
processed when it is turned OFF, output signal is ordinarily on while the power is ON, and turns OFF when the
signal is output.)
