70
[Step 5] The parameters input to MCON are listed as shown below. Indicate the Fieldbus
node addresses in Address.
Caution:
In the following slave, set the value the number of occupied station is added
to the current station number.
Caution: Caution for Setup of CC-Link IE Field Type
There is a section to set up the network number in addition to the
setup of current station number. Have the same network number set
up in this as the one in the connected PLC.
3.2 Initial Setting
