7028 Models 6C4 and 6E4
The Model 6C4 is a rack-mounted server system and the Model 6E4 is a deskside tower system.
Dimensions Rack (Model 6C4) Tower (Model 6E4)
Height 172.8 mm (6.8 in) 530 mm (20.9 in.)
4EIA Units
Width 444 mm (17.5 in.) 300 mm (11.8 in.)
Depth 609.6 mm (24.0 in.) 725 mm (28.5 in.)
Weight
Minimum configuration 32 kg (70.4 lbs.)
Maximum configuration 47.3 kg (104.8 lbs.)
Electrical
Power source loading (typical in kVA) 1-way, 2-way processors: 0.348, 4-way processor: 0.522
Power source loading (max. in kVA) 1-way, 2-way processors: 0.522, 4-way processor: 0.783
Voltage range (V ac) 100 to 127 or 200 to 240 (autoranging)
Frequency (hertz) 50 / 60
Voltage range (V dc) Not supported
Thermal output (typical) 1-way, 2-way processors: 1129 Btu/hr, 4-way processor: 1693 Btu/hr
Thermal output (max.) 1-way, 2-way processors: 1693 Btu/hr, 4-way processor: 2540 Btu/hr
Power requirements (typical) 1-way, 2-way processors: 330 watts, 4-way processor: 500 watts
Power requirements (max.) 1-way, 2-way processors: 500 watts, 4-way processor: 750 watts
Power factor - US, World Trade, Japan 0.96
Inrush current² 50 amps
Maximum altitude³,⁴ 2135 m (7000 ft.)
Temperature Requirements³ Operating
5 to 35°C
41 to 95°F)
Non-Operating
10 to 52°C
(50 to 126°F)
Humidity Requirements⁴ Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 27°C (80°F) 27°C (80°F)
Model 6C4 Noise Emissions
1, 5, 6
Operating Idle
L
WAd
6.1 bels 6.0 bels
<L
pA
>
m
44 dBA 43 dBA
Model 6E4 Noise Emissions
1, 7
Operating Idle
L
WAd
6.0 bels 5.9 bels
<L
pA
>
m
42 dBA 41 dBA
Install/Air Flow Maintenance of service clearance will allow proper air flow.
Service See service clearances for the 7014 T00 Rack
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions. See noise emissions note
4.
2. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
3. The upper limit of the dry bulb temperature must be derated 1°C per 137 m (450 ft.) above 915 m (3000 ft.).
4. The upper limit of the wet bulb temperature must be derated 1°C per 274 m (900 ft. ) above 305 m (1000 ft.).
5. Levels are for a single system installed in a T00 32 EIA rack with the center of the unit approximately 1500 mm
(59 in.) off the floor.
6. Levels apply to the following hardware configuration: 2 way 1 gigahertz processor, 3 Hard files, 2048 gigabytes of
RAM, Redundant system (Two 645 watt power supply, 2 processor fans).
7. Levels apply to the following hardware configuration: 2 way 1 gigahertz processor, 2 Hard files, 2048 gigabytes of
RAM, Non-redundant system (One 645 watt power supply, 1 processor fan).
8. All measurements made in accordance with ISO 7779 , and declared in conformance with ISO 9296.
82 Site and Hardware Planning Information
