7137 Disk Array Subsystem Models 412, 413, 414, and 415
Dimensions
Height 610 mm 24.0 in.
Width
Enclosure 210 mm 8.3 in.
Base 310 mm 12.2 in.
Depth 820 mm 32.3 in.
Weight
Empty 49 kg 109 lbs.
Maximum
Configuration
54 kg 119 lbs.
Electrical
Power source loading
(kVA)
0.33
Voltage range (V ac) 100 to 125 or 200 to 240
Frequency (hertz) 50 or 60
Thermal output 1050 Btu/hr
Power requirements 308 watts
Power factor 0.9
Maximum altitude 2134m (7000 ft.)
Temperature
Requirements
Operating
10 to 40°C
(50 to 110°F)
Non-Operating
1 to 52°C
(34 to 125°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8% to 80% 8% to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions* Operating Idle
L
WAd
5.9 bels 5.8 bels
L
pAm
N/A N/A
<L
pA
>
m
37 dBA 37 dBA
(4.5GB) 43 dBA No
Impulsive or
prominent discrete
tones
No
* See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
276 Site and Hardware Planning Information
