Chapter 2. Physical Characteristics of Systems
This chapter provides the physical characteristics for systems. This information can help you with physical
planning for the products you have ordered.
Note: The electrical and thermal information provided for systems does not include displays or a
operators terminal (such as an ASCII terminal). Be sure to include display or terminal characteristics
when planning the installation of system units.
7006 Graphics Workstation Models 41T, 41W, 42T, and 42W
Dimensions Desktop Deskside
Height 119 mm 4.7 in. 447 mm 17.6 in.
Width
1
447 mm 17.6 in. 215 mm 8.5 in.
Depth 451 mm 17.8 in. 451 mm 17.8 in.
Weight 12.7 kg 28 lbs.
Electrical
Power source loading (typical in kVA) 0.170
Voltage range (V ac) 100 to 127 or 200 to 240 (switchable)
Frequency (hertz) 50 or 60
Thermal output (typical) 290 Btu/hr
Power requirements (typical) 85 watts
Power factor 0.5 to 0.7
Inrush current
6
75 amps at 120 V ac, 150 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature Requirements Operating
16 to 32°C
(60 to 90.5°F)
Non-Operating
10 to 43°C
(50 to 110.5°F)
Humidity Requirements Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73.5°F) 27°C (80.5°F)
Noise Emissions
2
Operating Idle
L
WAd
5.2 bels 5.0 bels
L
pAm
41 dBA 38 dBA
<L
pA
>
m
36 dBA 34 dBA
Impulsive or prominent discrete tones No No
Clearances
3
Front Back Left Right
Install/Air Flow
4,5
35mm(1.5 in) 51mm(2 in) 25mm(1 in) 25mm(1 in)
Service 466mm(18 in) N/A N/A N/A
Footprint
4
Width Depth
Desktop 497mm (19.6 in) 537mm (21.1 in)
Deskside 215mm (8.5 in) 537mm (21.1 in)
1. Deskside width measurement includes the optional vertical stand.
2. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
3. Left and right measurements apply only when the system is used in the desktop position.
4. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
5. When placed in the vertical position, the system requires 25mm (1 in) at the bottom and top for proper air flow.
The necessary bottom clearance is provided by the optional vertical stand.
6. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
