7331 Model 205 140/280GB or Model 305 400/800GB 8-mm Tape Library
Dimensions
Height 637.0 mm 25.1 in.
Width 322.5 mm 12.7 in.
Depth 723.0 mm 28.5 in.
Weight
Minimum 45 kg 92.5 lbs.
Maximum 45 kg 92.5 lbs.
Electrical
Power source loading
(kVA)
0.34
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output 580 Btu/hr for two drives
Power requirements 340 watts
Power factor 0.95
Maximum altitude 3048 m (10,000 ft.)
Temperature
Requirements
Operating
5 to 40°C
(41 to 110°F)
Non-Operating
5 to 32°C
(41 to 90°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20% to 80% 20% to 80%
Wet Bulb 26°C (79°F) 26°C (79°F)
Noise Emissions* Operating Idle
L
WAd
6.2 bels 5.5 bels
L
pAm
N/A N/A
<L
pA
>
m
46 dBA 43 dBA
Impulsive or
prominent discrete
tones
No No
* See “Noise Emission Notes” on page 336 for definitions of emissions positions
318 Site and Hardware Planning Information
