IBM 7029 6C3 - 9114 Model 275

9114 Model 275
Dimensions
Height 535.0 mm (21.1 in.)
Width 190 mm (7.5 in.)
Depth 685 mm (27.0 in.)
Weight
Minimum configuration 32.0 kg (70.5 lbs.)
Maximum configuration 43.1 kg (94.8 lbs.)
Electrical
Power source loading (typical in kVA) 0.30
Power source loading (max. in kVA) 0.50
Voltage range (V ac) 100 to 127 or 200 to 240 (auto-ranging)
Frequency (hertz) 47 to 63
Voltage range (V dc) Not supported
Thermal output (typical) 1024 Btu/hr
Thermal output (max.) 1587 Btu/hr
Power requirements (typical) 300 watts
Power requirements (max.) 465 watts
Power factor - US, World Trade, Japan 0.95
Inrush current² 85 amps (max. at <10ms)
Maximum altitude³,⁴ 2135 m (7000 ft.)
Temperature Requirements³, ⁶ Operating
10 to 32°C
50 to 90°F)
Non-Operating
10 to 43°C
(50 to 109°F)
Humidity Requirements⁴ Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 27°C (80°F) 27°C (80°F)
Noise Emissions
1
Operating Idle
L
WAd
5.5 bels 5.5 bels
Install/Air Flow Maintenance of service clearance will allow proper air flow.
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions. See noise emissions note
4.
2. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle. The
inrush current exponentially decays over 5 ac cycles.
3. The upper limit of the dry bulb temperature must be derated 1°C per 137 m (450 ft.) above 915 m (3000 ft.).
4. The upper limit of the wet bulb temperature must be derated 1°C per 274 m (900 ft. ) above 305 m (1000 ft.).
5. Levels are for a single system installed in a T00 32 EIA rack with the center of the unit approximately 1500 mm
(59 in.) off the floor.
6. For systems with FC 6134: 60/150 GB 16-bit 8mm Internal Tape Drive, the maximum operating temperature is
limited. For additional information about this limitation, refer to the following table.
The following table lists maximum operating temperatures for FC 6134: 60/150 GB 16-bit 8mm Internal
Tape Drive at various altitudes.
0 305 m
(1000 ft)
610 m
(2000 ft)
914 m
(3000 ft)
1219 m
(4000 ft)
1524 m
(5000 ft)
1829 m
(6000 ft)
2134 m
(7000 ft)
2438 m
(8000 ft)
2743 m
(9000 ft)
3048 m
(10000 ft)
FC
6134
31°C
(88°F)
31°C
(88°F)
30°C
(86°F)
30°C
(86°F)
29°C
(84°F)
29°C
(84°F)
28°C
(82°F)
28°C
(82°F)
27°C
(81°F)
26°C
(79°F)
26°C
(79°F)
214 Site and Hardware Planning Information
