7017 Model S85
The S85 can be used with a T00 or T42 style I/O rack. See “Model T00 Rack” on page 31. The rack can
be ordered by feature code with your system.
Dimensions
Height 1577 mm 62.0 in.
Width 565 mm 22.2 in.
Depth 1200 mm 47.2 in.
Weight
Minimum (Configuration dependant) 400 kg 880 lbs.
Electrical
Power source loading 2.129KVA
(maximum in kVA)
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 - 60
Thermal output (Maximum) 6904 Btu/hr
Power requirements (Maximum) 2023 watts
Power factor 0.92 to 0.98
Inrush current³ 43 amps
Maximum altitude 2135 m (7000 ft.)
Temperature Requirements
4,5
Operating⁷
10 to 38°C
(50 to 100°F)
Non-Operating
1 1 to 60°C
(34 to 140°F)
Humidity Operating Non-Operating
Noncondensing 8 to 80% 8 to 80%
Wet Bulb Requirements⁶ 23°C (73°F) 23°C (73°F)
Noise Emissions
1,2
Operating Idle
L
WAd
6.9 bels 6.8 bels
L
pAm
N/A N/A
<L
pA
>
m
49.5 dBA 49.0 dBA
Impulsive or prominent discrete tones None None
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service See “Service Clearances for S80 or S85 System With T00 Style I/O Rack”
on page 36.
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. Noise emissions data for Model S85 are based on a system with the doors closed.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
4. The use of the PCI SSA Multi-Initiater/RAID EL in the Model S80 and S85 I/O Drawer 10 EIA limits the system
usage to a 28°C (82°F) environment maximum.
5. The upper limit of the dry bulb temperature must be derated 1 degree C per 137M (450 ft.) above 1295M (4250
ft.)
6. The upper limit of the wet bulb temperature must be derated 1 degree C per 274M (882 ft.) elevation above
1370M (4500 ft.)
7. For systems with FC 6120: 80/160 GB Internal Tape Drive with VXA Technology or FC 6134: 60/150 GB 16-bit
8mm Internal Tape Drive, the maximum operating temperature is limited. For additional information about this
limitation, refer to the following table.
Chapter 2. Physical Characteristics of Systems 49
