7011 POWERstation and POWERserver
®
220, and 230
Dimensions Desktop Deskside
Height 84 mm 3.3 in. 432 mm 17.0 in.
Width¹ 406 mm 16.0 in. 216 mm 8.5 in.
Depth 419 mm 16.5 in. 419 mm 16.5 in.
Weight
Minimum 9.0 kg 20 lbs.
Maximum 11.5 kg 25 lbs.
Electrical
Power source loading 0.17
(typical in kVA)
Voltage range (V ac) 100 to 127 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
340 Btu/hr
Power requirements
(typical)
100 watts
Power factor 0.5 to 0.7
Inrush current 50 amps at 120 V ac, 100 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions² Operating Idle
L
WAd
5.2 bels 5.0 bels
L
pAm
41 dBA 40 dBA
<L
pA
>
m
39 dBA 38 dBA
Impulsive or
prominent discrete
tones
No No
Clearances³ Front Back Left Right
Install/ Air Flow
4,5
35mm(1.5 in) 51mm(2 in) 25mm(1 in) 25mm(1 in)
Service 466mm(18 in) N/A N/A N/A
Footprint
4
Width Width
Desktop 456mm(18 in) 508mm(20 in)
Deskside 216mm(8.5 in) 508mm(20 in)
1. Deskside width measurement includes the optional vertical stand.
2. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
3. Left and right measurements apply only when the system is used in the desktop position.
4. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
5. When placed in the vertical position, the Model 220 requires 25 mm (1 in) at the bottom and top for proper air
flow. The necessary bottom clearance is provided by the optional vertical stand.
16 Site and Hardware Planning Information
