1/2-Inch 9-Track Tape Drive Drawer
Dimensions
Height 222 mm 8.75 in.
(6 EIA units)
Width 483 mm 19.00 in.
Depth 679 mm 26.75 in.
Weight
Minimum 48.2 kg 106 lbs.
Maximum 48.2 kg 106 lbs.
Electrical
Power source loading 0.2
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 240 (selectable)
Frequency (hertz) 50 or 60
Thermal output
(typical)
410 Btu/hr
Power requirements
(typical)
120 watts
Power factor 0.5 to 0.7
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20 to 80% 20 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
40 Site and Hardware Planning Information
