Enterprise Server Models S70 and S7A (7017, 7013, 7015)
System Rack
Dimensions
Height 1577 mm 62.0 in.
Width 567 mm 22.3 in.
Depth 1041 mm 40.9 in.
Weight
Minimum 400 kg 880 lbs.
(Configuration
dependant)
Electrical
Power source loading 1.887KVA
(maximum in kVA)
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 - 60
Thermal output
(Maximum)
5796 Btu/hr
Power requirements
(Maximum)
1698 watts
Power factor 0.9
Inrush current³ 102 amps
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
4,5
Operating
10 to 37.8°C
(50 to 100°F)
Non-Operating
1 to 60°C
(34 to 140°F)
Humidity Operating Non-Operating
Noncondensing 8 to 80% 8 to 80%
Wet Bulb
Requirements⁶
23°C (73°F) 23°C (73°F)
Noise Emissions
1,2
Operating Idle
L
WAd
7.0 bels 7.0 bels
L
pAm
N/A N/A
<L
pA
>
m
N/A N/A
Impulsive or prominen
discrete tones
No No
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service See “Service Clearances for System in an S70, S7A, or S80 I/O Rack” on page 54.
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. Noise emissions data for Models S70 and S7A are based on a system with the doors closed.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
4. The use of the PCI SSA Multi-Initiater/RAID EL in the Model S70 I/O Drawer limits the system usage to a 28°C
(82°F) environment maximum.
5. The upper limit of the dry bulb temperature must be derated 1 degree C per 137M (450 ft.) above 1295M (4250
ft.)
6. The upper limit of the wet bulb temperature must be derated 1 degree C per 274M (882 ft.) elevation above
1370M (4500 ft.)
46 Site and Hardware Planning Information
