9516 TFT LCD Color Display
9516 TFT LCD Color Display with a maximum viewable image size of 408 mm (16.1 inches) measured
diagonally.
Dimensions
Height (Display only) 431 mm 17.0 in
(Display with
Tilt/Swivel)
511 mm 21.1 in
Width 408 mm 16.1 in
Depth 250 mm 9.8 in
Weight 9.9 kg 21.8 lbs
Electrical
Voltage range (V ac) 100 to 240
Frequency (hertz) 50 or 60
Thermal output
(maximum)
188 Btu/hr
Power requirements
(in active mode VESA
Standby)
18 watts
(in energy saving
mode VESA off)
8 watts
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 5 to 80 % 5 to 80 %
Noise Emissions* Operating Idle
L
WAd
4.5 bels N/A bels
Clearances Front Back Left Right
Service Install so that air vents are not blocked.
* See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
Chapter 4. Physical Characteristics of Displays 223
