7038 Model 6M2 (Eserver pSeries 650)
Dimensions
Height 351 mm (13.8 in)
Width 445 mm (17.5 in.)
Depth 760 mm (29.9 in.)
Weight 93 kg (205 lbs)
Electrical
Power source loading (typical) 8-way processor: 1.126 kVA
Power source loading (max.) 8-way processor: 1.684 kVA
Voltage range 200 to 240 V ac, V dc not supported
Frequency 50 or 60 Hz
Thermal output (typical) 8-way processor: 3,652Btu/hr
Thermal output (max.) 8-way processor: 5,461 Btu/hr
Power requirements (typical) 8-way processor: 1,070 watts
Power requirements (max.) 8-way processor: 1,600 watts
Power factor 0.95
Inrush current² 67 amps at 200 V ac, 60 Hz
87 amps at 230 V ac, 50 Hz
Maximum altitude
3, 4
3048 m (10000 ft.)
Temperature Requirements³ Operating
10 to 38°C
(50 to 100°F)
Non-Operating
1 to 43°C
(34 to 109°F)
Storage
1 to 60°C
(34 to 140°F)
Humidity Requirements⁴ Operating Non-Operating Storage
(Noncondensing) 8 to 80% 8 to 80% 5 to 80%
Wet Bulb 23°C (73°F) 27°C (81°F) 29°C (84.2°F)
Noise Emissions
1, 5, 6
Operating Idle
L
WAd
6.1 bels
5
6.1 bels
5
<L
pA
>
m
44 dBA
6
44 dBA
6
Install/Air Flow Maintenance of service clearance will allow proper air flow.
Service Clearances See “T00 and T42 Service Clearances and Caster Location” on page 33 for T00 or
T42 rack service clearances.
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions. See noise emissions note
4.
2. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
3. The upper limit of the dry bulb temperature must be derated 1°C per 137 m (450 ft.) above 915 m (3000 ft.).
4. The upper limit of the wet bulb temperature must be derated 1°C per 274 m (900 ft. ) above 305 m (1000 ft.).
5. The L
WAd
emission increases to 6.5 bels with a configuration of one 7038-6M2 and four 7311-D10 drawers.
6. The L
pA
>
m
emission increases to 48 dBA with a configuration of one 7038-6M2 and four 7311-D10 drawers.
86 Site and Hardware Planning Information
