1. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
2. For altitudes above 915 meters, the maximum temperature limit is derated by 1 degree C for every 137 meters of
elevation above 915 meters.
3. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
4. For systems with FC 6120: 80/160 GB Internal Tape Drive with VXA Technology or FC 6134: 60/150 GB 16-bit
8mm Internal Tape Drive, the maximum operating temperature is limited. For additional information about this
limitation, refer to the following table.
The following table lists maximum operating temperatures for system features at various altitudes.
0 305 m
(1000 ft)
610 m
(2000 ft)
914 m
(3000 ft)
1219 m
(4000 ft)
1524 m
(5000 ft)
1829 m
(6000 ft)
2134 m
(7000 ft)
FC 6120 34°C
(93°F)
34°C
(93°F)
33°C
(91°F)
33°C
(91°F)
33°C
(91°F)
32°C
(90°F)
32°C
(90°F)
31°C
(88°F)
FC 6134 32°C
(90°F)
32°C
(90°F)
31°C
(88°F)
31°C
(88°F)
31°C
(88°F)
30°C
(86°F)
30°C
(86°F)
30°C
(86°F)
7026 Model 6M1 CEC Drawer
The RS/6000 Enterprise Server Model M80 and Eserver pSeries 660 Model 6M1 systems are
multiprocessor, multibus systems packaged in two to five drawers. The processors and memory are
packaged in an 8 EIA-unit central electronics complex (CEC) drawer, and the optional DASD and I/O
devices are in 5 EIA-unit I/O drawers. The basic system consists of one CEC drawer and one I/O drawer
in the same rack. The system is expanded by adding up to three additional I/O drawers in a minimum of
two racks. For technical information on the I/O Drawer see “I/O Drawer 5 EIA” on page 79.
Dimensions
Height
Width
Depth
355.6 mm
445.5 mm
825.5 mm
14.0 in.
17.5 in.
32.5 in.
Weight
Minimum
Maximum
69.7 kg
74.6 kg
158 lbs.
169 lbs.
Electrical
Power source loading typical in kVA
Power source loading maximum in kVA
Voltage range (V ac)
Frequency (hertz)
Thermal output (typical)
Thermal output (maximum)
Power requirements (typical)
Power requirements (maximum)
Power factor
Inrush current
Maximum altitude
0.45
0.69
200 to 240
50 or 60
M80: 1265 Btu/hr
6M1: 1450 Btu/hr
M80: 1877 Btu/hr
6M1: 2218 Btu/hr
M80: 370 watts
6M1: 425 watts
M80: 550 watts
6M1: 650 watts
0.95
34 amps
2135 m (7000 ft.)
Temperature Requirements Operating⁴
10 to 38°C
(50 to 100°F)
Non-Operating (Power Off)
10 to 52°C
(50 to 125°F)
70 Site and Hardware Planning Information
