3570 Model B02 and C02
Dimensions
Height 217 mm 8.5 in.
Height (with stand) 242.4 mm 9.5 in.
Width 483 mm 19.0 in.
Depth 771 mm 30.4 in.
Weight
Maximum 40.0 kg 88.2 lbs
Maximum (with stand) 44.8 kg 98.7 lbs
Electrical
Power source loading 0.13
(typical in kVA)
Voltage range (V ac) 100 to 127 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
444 Btu/hr
Power requirements
(typical)
130 watts
Power factor 0.99 (100 V ac) or 0.95 (200 V ac)
Inrush current¹ 30 amps at 120 V ac, 40 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(61 to 90°F)
Non-Operating
10 to 43°C
(50 to 109°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 26°C(79°F) 27°C(81°F)
Noise Emissions² Operating Idle
L
WAd
5.8 bels 5.5 bels
L
pAm
N/A N/A
<L
pA
>
m
43dBA 38dBA
Impulsive noise None None
Prominent discrete
tones
None None
Clearances Front Back Left Right
Install/Air Flow³ 76 mm (3 in) 76 mm (3 in) None None
Service No additional clearance is needed for service.
1. Inrush current for each line cord. This model has two line cords.
2. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
3. Air flow is 50 CFM.
248 Site and Hardware Planning Information
