2102 Model F10 Fibre Channel RAID Storage Server
Dimensions
Height 175 mm 6.88 in.
(4 EIA units)
Width 445 mm 17.5 in.
Depth 635 mm 25.0 in.
Weight 36 kg 79 lbs.
Electrical
Power source loading:
Maximum operating 0.329 kVA
Voltage range (V ac) 100 to 125 or 200 to 240
Frequency (hertz) 50 or 60
Thermal output
(Maximum)
731 Btu/hr
Power Requirements 214 watts
Inrush current 4 amps. at 120 Vac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
(see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Humidity
Requirements
(see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Noise Emissions (see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Clearances (see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Chapter 5. Physical Characteristics of the 2100 Series 231
