S70 SCSI I/O Drawer 7 EIA
Dimensions
Height 306.2 mm 12.1 in.
Width 442.4 mm 17.4 in.
Depth 748.2 mm 29.5 in.
Weight
Minimum configuration 43 kg 95 lbs.
Maximum configuration 61 kg 135 lbs.
Electrical AC DC
Power source loading 0.4 0.4
(typical in kVA)
Power source loading 1.0 1.0
(maximum in kVA)
Voltage range 200 to 240 V ac 40 to 60 VDC
Frequency (hertz) 50 / 60 N.A
Thermal output (typical) 1228 Btu/hr 1365 Btu/hr
Thermal output (maximum) 3071 Btu/hr 3412 Btu/hr
Power requirements (typical) 360 watts 400 watts
Power requirements (maximum) 900 watts 1000 watts
Power factor 0.9 N/A
Inrush current³ 120 amps 300 amps
Maximum altitude 2135 m (7000 ft.) 2135 m (7000 ft.)
Temperature Requirements⁴ Operating
10 to 40°C⁴
(50 to 104°F)
Non-Operating
10 to 52°C
(50 to 125.6°F)
Humidity (Noncondensing) Operating Non-Operating
Without tape drive 8 to 80% 8 to 80%
With tape drive 20 to 80% 20 to 80%
Wet Bulb Requirements
Without tape drive 27°C (80°F) 27°C (80°F)
With tape drive 23°C (73°F) 27°C (80°F)
Noise Emissions
1,2
Operating Idle
L
WAd
5.9 bels 5.8 bels
L
pAm
N/A N/A
<L
pA
>
m
39 dBA 38 dBA
Impulsive or prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service (See “Service Clearances for System in an S70, S7A, or S80 I/O Rack” on
page 54)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. Noise emissions data for the Model S70 SCSI I/O Drawer 7 EIA are based on the I/O drawer mounted in a rack.
See “S70, S7A and S80 I/O Rack” on page 54.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
4. Use of the PCI SSA Multi-Initiator/RAID EL in this S70 I/O Drawer limits the system usage to a 28°C (82°F)
environment maximum.
52 Site and Hardware Planning Information
