Acoustical Noise Emissions
Acoustical Characteristic
Product Configuration Declared A-Weighted Sound Power
Level, L
WAd
(B)
Declared A-Weighted Sound Pressure
Level, LpAm (dB)
Operating Idle Operating Idle
7040 Acoustical Doors 7.5 7.5 57 57
7040 Slimline Doors 7.9 7.9 62 62
Notes:
1. Noise levels cited are for a typical configuration (Bulk Power, CEC cage, battery option, media drawer, and two
I/O drawers).
2. The 0.6-B (6-dB) reduction in noise emission levels with the acoustical rear door corresponds to a factor of 4
reduction. That is, the noise level of a single frame with thin covers is about the same as the noise level of four
frames with acoustical covers.
3. L
WAd
is the upper-limit A-weighted sound power level; LpAm is the mean A-weighted sound pressure level at the
1-meter bystander positions; 1 B = 10 dB.
4. All measurements made in conformance with ISO 7779 and declared in conformance with ISO 9296.
Environmental Specifications
Environmental Specification Operating Non-Operating Storage Shipping
Temperature 10 to 32°C
(50 to 90°F)
Max. of 24 ° C
(75.2 ° F) with
4mm tape or DVD
RAM in rear
positions of the
Media Subsystem
10 to 43°C
(50 to 109°F)
1 to 60°C
(34 to 140°F)
–40 to 60°C
(–40 to 140°F)
Relative Humidity
(Noncondensing)
8 to 80 % 8 to 80 % 5 to 80 % 5 to 100 %
Maximum Wet Bulb 23°C (73°F) 27°C (73°F) 29°C (84°F) 29°C (84°F)
Notes:
1. When an IBM-approved vapor bag and desiccant packets are used to protect the system, storage specifications
are valid for 6 months and shipping specifications are valid for 1 month. Otherwise, storage and shipping
specifications are valid for two weeks each.
2. The upper limit of the dry bulb temperature must be derated 1 degree C per 189 m (619 ft.) above 1295 m (4250
ft.). Maximum altitude is 3048 m (10,000 ft.).
Weight Distribution
The following table shows dimensions and weights used to calculate floor loading for the Eserver pSeries
690. All floor-loading calculations are intended for a raised-floor environment.
1 Frame with Slimline Covers 1 Frame with Acoustical Covers
Weight 1085 kg (2392 lbs.) 1099 kg (2422 lbs.)
Width 750 mm (29.5 in.) 750 mm (29.5 in.)
Depth 1173 mm (46.2 in.) 1173 mm (46.2 in.)
136 Site and Hardware Planning Information
