2102 Model D00 Expandable Storage Unit
For more information on the 2102 Model D00 Expandable Storage Unit see page 230.
Dimensions
Height 132 mm 5.2 in.
(3 EIA units)
Width 480 mm 18.9 in.
Depth 575 mm 22.6 in.
Weight
Minimum 31 kg 69 lbs.
Maximum 42 kg 92 lbs.
Electrical
Power source loading
(typical in kVA)
0.39
Voltage range (V ac) 100 to 125 or 200 to 240
Frequency (hertz) 50 or 60
Thermal output
(typical)
1315 Btu/hr
Power requirements
(typical)
385 watts
Inrush current 2.52 amps
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
(see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Humidity
Requirements
(see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Noise Emissions (see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
Clearances (see specifications for rack on page 2101 Model 100 Seascape Solution Rack on page 229)
232 Site and Hardware Planning Information
