Total System Power Consumption
The following tables contain minimum and maximum power consumption for the 1.1 GHz and 1.5 GHz
Eserver pSeries 670. Minimum power consumption is based on a configuration consisting of a single 4
GB memory card, 1 PCI card per I/O subsystem, and 1 DASD device per I/O subsystem.
Maximum power consumption is based on a configurations consisting of a two 32 GB memory cards per
MCM module in 1.1 GHz machines and two 64 GB memory cards per MCM module in 1.5 GHz machines,
maximum PCI cards (20 per I/O drawer), and maximum DASD (16 per I/O drawer).
Power consumption calculations are estimates. Actual values may vary.
Calculate heat load (Btu per hour) by multiplying the power (in watts) for the configuration by a factor of
3.4.
Note: Certain system configurations only support a maximum number of I/O drawers. If a system does not
support a particular count of I/O drawers, it is indicated with ″N/A″.
Number of I/O Drawers
(7040-61D)
1.1 GHz 4-way Modules (minimum
power consumption, in watts)
1.1 GHz 4-way Modules (maximum power
consumption, in watts)
1 1835 2966
2 2203 4014
Number of I/O Drawers
(7040-61D)
1.1 GHz 8-way Modules (minimum
power consumption, in watts)
1.1 GHz 8-way Modules (maximum
power consumption, in watts)
8-way 16-way 8-way 16-way
1 1911 2867 3042 4586
2 2279 3235 4090 5634
3 N/A 3603 N/A 6682
Number of I/O Drawers
(7040-61D)
1.5 GHz 4-way Modules (minimum
power consumption, in watts)
1.5 GHz 4-way Modules (maximum power
consumption, in watts)
1 1714 2931
2 2082 3979
Number of I/O Drawers
(7040-61D)
1.5 GHz 8-way Modules (minimum
power consumption, in watts)
1.5 GHz 8-way Modules (maximum
power consumption, in watts)
8-way 16-way 8-way 16-way
1 1839 2723 3056 4614
2 2207 3091 4104 5662
3 N/A 3459 N/A 6710
140 Site and Hardware Planning Information
