7014 Model S00 Rack
Dimensions
Height 1577 mm 62.0 in.
Width 650 mm 25.5 in.
Depth 1019 mm 40.1 in.
Weight
1
Base Rack 159 kg 349 lbs.
Full Rack 594 kg 1309 lbs.
Electrical² (sum specified values for
drawers or enclosures in rack)
DC Rack
Power source loading
maximum in kVA³
8.4
Voltage range (V dc) -40 to -60
AC Rack
Power source loading
maximum in kVA (per
PDB)⁴
4.8
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Humidity
Requirements
(see specifications for drawers or enclosures)
Noise Emissions (see specifications for drawers or enclosures)
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service 915mm(36 in) 915mm(36 in) 915mm(36 in) 915mm(36 in)
Notes:
1. Configuration dependent, base weight plus the weight of the drawers mounted in the rack. The rack can support
up to a maximum of 13.6 kg (30) lbs/EIA (Unit)
2. The total rack power should be derived from the sum of the power used by the drawers in the rack.
28 Site and Hardware Planning Information
