3995 Model 163
Dimensions
Height 1800 mm 70.9 in.
Width 692 mm 27.3 in.
Depth 943 mm 37.1 in.
Weight
Minimum 408 kg 900 lbs
Maximum N/A N/A
Electrical
Power source loading 0.25
(typical in kVA)
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Thermal output
(typical)
750 Btu/hr
Power requirements 220 watts
Power factor 0.89
Inrush current 10 amps
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
10 to 43°C
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C(73°F) 27°C(80°F)
Noise Emissions* Operating Idle
L
WAd
6.5 bels 5.5 bels
L
pAm
N/A N/A
<L
pA
>
m
46 dBA 42 dBA
Impulsive noise Yes No
Prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow 1020mm(40 in) 1020mm(40 in) 559mm(22 in) 559mm(22 in)
Service Install so that it can be moved to an area providing 760 mm(30 in) on each side.
* See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
Chapter 6. Physical Characteristics of the 3000 Series 259
