7133 Models 500 and 600 Deskside SSA Subsystem
Dimensions
Height 610 mm 24.0 in.
Width (at pedestal) 210 mm 8.3 in.
Depth 820 mm 32.3 in.
Weight
Minimum 58.5 kg 129 lbs.
Maximum 72.5 kg 160 lbs.
Electrical
Power source loading:
Maximum start-up 0.657 kVA
Maximum operating 0.499 kVA
Maximum idling 0.45 kVA
Power factor greater than 0.95
Voltage range (V ac) 100 to 240
Frequency (hertz) 50 or 60
Thermal output
(Maximum)
2074 Btu/hr
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
(See note)
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
Avg. Max. Avg. Max.
L
WAd
6.0 bels 6.8 bels 5.5 bels 6.6 bels
L
pAm
N/A N/A
<L
pA
>
m
50 dBA 59 dBA 45 dBA 56 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 152 mm(6 in) N/A N/A N/A
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by broken lines on the footprint.
Note: The recommended operating temperature is 22°C (72°F) or lower. At lower temperatures, the risk of failure in
the unit is reduced. If the operating temperature is above 22°C (72°F) for long periods of time, the unit will be
exposed to a greater risk of failure from external causes.
272 Site and Hardware Planning Information
