7013 Models 58H, 590, 59H, 591, and 595
Dimensions
Height 610 mm 24 in.
Width 360 mm 14.2 in.
Depth 675 mm 26.6 in.
Weight
Minimum 36.7 kg 81 lbs.
Maximum 53.1 kg 117 lbs.
Electrical
Power source loading 0.5
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
1620 Btu/hr
Power requirements
(typical)
550 watts
Power factor 0.8 to 1.0
Inrush current 34 amps at 120 V ac, 68 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(61 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
(Noncondensing)
Operating Non-Operating
Without tape media 8 to 80% 8 to 80%
With tape media 20 to 80% 20 to 80%
Wet Bulb
Requirements
Without tape media 27°C (80°F) 27°C (80°F)
With tape media 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
5.8 bels 5.3 bels
L
pAm
N/A N/A
<L
pA
>
m
39 dBA 38 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² N/A 152 mm(6 in) 76 mm(3 in) 76 mm(3 in)
Service Install so that it can be moved to an area providing 760 mm (3 in) on each side.
Footprint
2
Width
512mm(20.2 in)
Depth
828mm(32.6 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
Chapter 2. Physical Characteristics of Systems 25
