7212 Model 102 External Storage Device
Dimensions
Height 44 mm 1.7 in.
Width 430 mm 16.8 in.
Depth 485 mm 19.0 in.
Weight
3
8.3 kg 18.2 lbs.
Electrical
Power source loading
(kVA)
0.047 @ 120 Vac
Voltage range (V ac) 100 to 127 or 200 to 240 (auto-ranging)
Frequency (hertz) 50 or 60
Thermal output
(maximum)
206 Btu/hr @240 Vac
Power requirements
(typical)
60 watts
Power factor 0.8 to 0.9
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 52°C
(50 to 126°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 23°C (73°F)
Noise Emissions¹ Operating Idle
L
WAd
5.5 bels 5.3 bels
L
pAm
51 dBA 47 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 152 mm(6 in) N/A N/A N/A
Footprint
2
Width
430mm(16.8 in)
Depth
789mm(31 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
3. Weight with two DDS-4, 4 mm tape drives installed.
Chapter 8. Physical Characteristics of the 7200 Series 311
