7029 Models 6C3 and 6E3
The Model 6C3 is a rack-mounted server system and the Model 6E3 is a deskside tower system.
Dimensions Rack (Model 6C3) Tower (Model 6E3)
Height 178 mm (7.0 in) 533.0 mm (21.0 in.)
4EIA Units
Width 437 mm (17.2 in.) 201 mm (7.9 in.)
Depth 508 mm (20.0 in.) 584 mm (23.0 in.)
Weight
Minimum configuration 35.5 kg (78.0 lbs.) 35.5 kg (78.0 lbs.)
Maximum configuration 43.1 kg (94.8 lbs.) 43.1 kg (94.8 lbs.)
Electrical
Power source loading (typical in kVA) 0.30
Power source loading (max. in kVA) 0.50
Voltage range (V ac) 100 to 127 or 200 to 240 (auto-ranging)
Frequency (hertz) 47 / 63
Voltage range (V dc) Not supported
Thermal output (typical) 1024 Btu/hr
Thermal output (max.) 1536 Btu/hr
Power requirements (typical) 300 watts
Power requirements (max.) 450 watts
Power factor - US, World Trade, Japan 0.95
Inrush current² 85 amps (max. at <10ms)
25 amps (max at 10 to 150ms
Maximum altitude³,⁴ 2135 m (7000 ft.)
Temperature Requirements³, ⁶ Operating
10 to 40°C
50 to 104°F)
Non-Operating
10 to 43°C
(50 to 109°F)
Humidity Requirements⁴ Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 27°C (80°F) 27°C (80°F)
Model 6C3 Noise Emissions
1, 5
Operating Idle
L
WAd
6.0 bels 6.0 bels
Model 6E3 Noise Emissions
1
Operating Idle
L
WAd
6.1 bels 6.1 bels
Install/Air Flow Maintenance of service clearance will allow proper air flow.
Service See service clearances for the 7014 T00 Rack
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions. See noise emissions note
4.
2. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
3. The upper limit of the dry bulb temperature must be derated 1°C per 137 m (450 ft.) above 915 m (3000 ft.).
4. The upper limit of the wet bulb temperature must be derated 1°C per 274 m (900 ft. ) above 305 m (1000 ft.).
5. Levels are for a single system installed in a T00 32 EIA rack with the center of the unit approximately 1500 mm
(59 in.) off the floor.
6. For systems with FC 6134: 60/150 GB 16-bit 8mm Internal Tape Drive, the maximum operating temperature is
limited. For additional information about this limitation, refer to the following table.
Chapter 2. Physical Characteristics of Systems 83
