7235 POWER GTO
™
Models 01i and 02i Graphics Subsystem
Dimensions Desktop Deskside
Height 160 mm 6.3 in. 466 mm 18.3 in.
Width 460 mm 18.0 in. 160 mm 6.3 in.
Width at pedestal
(deskside)
241 mm 9.5 in.
Depth 525 mm 21.0 in. 525 mm 21.0 in.
Weight
Minimum 16 kg 35 lbs. 16 kg 35 lbs.
Maximum 16 kg 35 lbs. 16 kg 35 lbs.
Electrical
Power source loading 0.5
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
850 Btu/hr
Power requirements
(typical)
250 watts
Power factor 0.5 to 0.7
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
5.8 bels 5.5 bels
L
pAm
N/A N/A
<L
pA
>
m
54 dBA N/A
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 152 mm(6 in) N/A N/A N/A
Footprint
2
Width Depth
Desktop 460mm(18 in) 830mm(33 in)
Deskside 241mm(9.5 in) 830mm(33 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
312 Site and Hardware Planning Information
