7009 Compact Server C10 and C20
Dimensions
Height 394 mm 15.5 in.
Width 191 mm 7.5 in.
Width with pedestal 241 mm 9.5 in.
Depth 432 mm 17.0 in.
Weight
Minimum 16 kg 35.0 lbs.
Maximum 18 kg 39.5 lbs.
Electrical
Power source loading
(maximum in kVA)
0.232
Voltage range (V ac) 100 to 127 or 200 to 240 (switchable)
Frequency (hertz) 50 or 60
Thermal output (max) (C10) 512 Btu/hr
(C20) 544 Btu/hr
Power requirements (max) (C10) 150 watts
(C20 ) 160 watts
Power factor 0.5 to 0.7
Inrush current³ 75 amps at 120 V ac,
150 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity Requirements Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
5.7 bels 5.3 bels
L
pAm
NA NA
<L
pA
>
m
41 dBA 38 dBA
Impulsive or prominent
discrete tones
No No
Clearances Front Back Left Right
Install/Air Flow² 76 mm(3 in) 152 mm(6 in) N/A N/A
Service Install so that it can be moved to an area providing 457 mm (18 in) on the front and
457 mm (18 in) on the left side.
Footprint² Width
241 mm(9.5 in)
Depth
660 mm(26 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
12 Site and Hardware Planning Information
