Power and Electrical Requirements
Dual power and line cords are standard on the Eserver pSeries 655. For maximum availability, each of
the line cords should be fed from independent power grids. Some configurations require drawing current
from two power feeds in a non-redundant manner.
The following table illustrates electrical and thermal characteristics for the Eserver pSeries 655.
Electrical/Thermal Characteristic
Rated Voltage (V ac, 3 phase) 200 to 240 380 to 415 480
Rated Current, Line Cord with 60-A Plug,
FC 8688 or 8689 (amps, per phase)
48 — —
Rated Current, All Other Line Cords
(amps, per phase)
60 32 24
Frequency (Hz) 50 to 60 50 to 60 50 to 60
Power (Maximum in kW) 31.8 31.8 31.8
Typical, Full Load Power Factor (pf) 0.99 0.97 0.95
Inrush Current (Maximum A) 162 162 162
Thermal Output (Maximum kBtu/hr) 102 102 102
Note: Inrush currents occur only at initial application of power (very short duration for charging capacitors). No
inrush currents occur during the normal power off-on cycle.
The following table illustrates the line cord options for the Eserver pSeries 655 with their geographic,
breaker rating, and cord information.
3-Phase Supply Voltage (50/60
Hz)
200-240 V 200-240 V 380-415 V 480 V
Recommended
Customer-Circuit-Breaker Rating
(see Note below)
60 A (60-A Plug)
or
100 A (100-A Plug)
60 A (60-A Plug) 30 A 25 A
Cord Information 6 and 14 foot, 6
AWG line cord
(60-A Plug)
or
6 and 14 foot, 6
AWG line cord
(100-A Plug)
14 foot, 6 AWG
line cord,
(electrician
installed)
14 foot, 8 AWG
line cord,
(electrician
installed)
6 and 14 foot, 10
AWG line cord
Recommended Receptacle IEC309, 60 A, type
460R9W (not
provided)
or
IEC309, 100A,
type 4100R9W
(not provided)
Not specified,
electrician installed
Not specified,
electrician installed
IEC309, 30 A, type
430R7W (not
provided)
Note: The exact circuit breaker ratings may not be available in all countries. Where the specified circuit breaker
ratings are not acceptable, use the nearest available rating. Use of a time delayed circuit breaker is recommended.
Use of a GFI circuit breaker is not recommended.
