Enterprise Server Model S80 (7017)
The S80 can be used with a T00 or T42 style I/O rack. See “Model T00 Rack” on page 31. The rack can
be ordered by feature code with your system.
System Rack
Dimensions
Height 1577 mm 62.0 in.
Width 567 mm 22.3 in.
Depth 1041 mm 40.9 in.
Weight
Minimum (Configuration dependant) 400 kg 880 lbs.
Electrical
Power source loading 2.129KVA
(maximum in kVA)
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 - 60
Thermal output (Maximum) 6904 Btu/hr
Power requirements (Maximum) 2023 watts
Power factor 0.92 to 0.98
Inrush current³ 43 amps
Maximum altitude 2135 m (7000 ft.)
Temperature Requirements
4,5
Operating
10 to 37.8°C
(50 to 100°F)
Non-Operating
1 1 to 60°C
(34 to 140°F)
Humidity Operating Non-Operating
Noncondensing 8 to 80% 8 to 80%
Wet Bulb Requirements⁶ 23°C (73°F) 23°C (73°F)
Noise Emissions
1,2
Operating Idle
L
WAd
6.9 bels 6.8 bels
L
pAm
N/A N/A
<L
pA
>
m
49.5 dBA 49.0 dBA
Impulsive or prominent discrete tones None None
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service See “Service Clearances for System in an S70, S7A, or S80 I/O Rack” on
page 54. Or, see “Service Clearances for S80 or S85 System With T00
Style I/O Rack” on page 36.
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. Noise emissions data for Model S80 are based on a system with the doors closed.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
4. The use of the PCI SSA Multi-Initiater/RAID EL in the Model S7A and S80 I/O Drawer 10 EIA limits the system
usage to a 28°C (82°F) environment maximum.
5. The upper limit of the dry bulb temperature must be derated 1 degree C per 137M (450 ft.) above 1295M (4250
ft.)
6. The upper limit of the wet bulb temperature must be derated 1 degree C per 274M (882 ft.) elevation above
1370M (4500 ft.)
Chapter 2. Physical Characteristics of Systems 47
