IBM 7029 6C3 - Page 203

11P4757 Frame tie-down Kit (Short - Raised Floor) (RPQ 8A1185)
Item Part Number Qty Description
Illustration on page 191. 44P0673 4 Turnbuckle Assembly (short)
Item 3 in illustration on page
186.
11P3527 2 Shipping bar (lower)
Item 5 in illustration on page
186.
11P3529 4 Hinge plate
Item 8 in illustration on page
186.
11P3530 2 Latch plate
Item 6 in illustration on page
186.
11P3531 2 EQ support
Item 2 in illustration on page
186.
11P3532 2 Shipping bar (upper)
Item 7 in illustration on page
186.
76X4687 2 Latch bolt
Item 1 in illustration on page
186.
1624804 20 Screw (hex flange, 20mm, long)
Item 9 in illustration on page
186.
1621546 8 Screw (hex, 25mm, long, hinge)
Item 10 in illustration on page
186.
1622307 8 Washer (M-8, hinge)
11P4758 Frame tie-down Kit (Long - Raised Floor) (RPQ 8A1186)
Item Part Number Qty Description
Illustration on page 191. 44P0674 4 Turnbuckle Assembly (long)
Item 3 in illustration on page
186.
11P3527 2 Shipping bar (lower)
Item 5 in illustration on page
186.
11P3529 4 Hinge plate
Item 8 in illustration on page
186.
11P3530 2 Latch plate
Item 6 in illustration on page
186.
11P3531 2 EQ support
Item 2 in illustration on page
186.
11P3532 2 Shipping bar (upper)
Item 7 in illustration 186. 76X4687 2 Latch bolt
Item 1 in illustration on page
186.
1624804 20 Screw (hex flange, 20mm, long)
Item 9 in illustration on page
186.
1621546 8 Screw (hex, 25mm, long, hinge)
Item 10 in illustration on page
186.
1622307 8 Washer (M8, hinge)
Mounting Internal Rack Components: To mount the internal rack components, do the following:
Attention: This procedure is performed by the service representative.
1. Using four M-8 (20 mm) screws (item 1 in illustration on page 186), install the top shipping bar (item
2 in illustration on page 186) at EIA unit location 32.
Chapter 2. Physical Characteristics of Systems 185
