iSeries and AS/400e Servers
70 iSeries Handbook
Summary
Base
System
System Unit
Expansion
#7104
PCI
Expansion
Tower
#5075
Total
Maximum
LPAR
Maximum
Disk Storage (GB)
Integrated Minimum 8.58 - - 8.58 -
Integrated Maximum 210.9 421.9 210.9 843.9 843.9
External Maximum (Note 7) 808.7 - 808.7 808.7 808.7
Total Maximum 843.9 421.9 808.7 843.9 843.9
DASD Arms Maximum 2312232424
Arms Internal 6 12 6 24 24
LUNs External 23 - 23 23 23
Physical Packaging
External HSL Ports 2 - - 2 2
External HSL Loops 1 - - 1 1
#5075 Towers supported 1 - - 1 1
#5074 Towers supported - ----
External xSeries Servers supported 2 - - 2 2
Embedded IOP 1 - 1 2 2
PCI Card Slots 7 - 8 15 15
Maximum PCI IOA Cards 6 - 7 13 13
Communication Lines (Note 4) 26 - 34 50 50
LAN Ports 4-588
Integrated Netfinity Servers 1 - 2 3 3
Twinaxial Workstation Controllers 4 - 6 6 6
Twinaxial Workstations 160 - 240 240 240
Internal/DlVD-ROM/DVD-RAM/Tape(6) 2 - - 2 2
External Tape 3 - 3 3 6
External CD-ROM / DVD-RAM (Note 6) 3 3 3 6
Tape Libraries (Note 3) 3 - 3 3 6
Optical Libraries 4 - 4 4 8
Diskettes (5 ¼-inch or 8-inch) - ----
Cryptographic Processor 3 - 3 3 3
Note 1: Commercial Processing Workload (CPW) is used to measure the performance of all iSeries and AS/400e
processors announced from September 1996 onward. The CPW value is measured on maximum
configurations. The type and number of disk devices, the number of workstation controllers, the amount of
memory, the system model, other factors, and the application running determine what performance is
achievable. With the introduction of the Dedicated Servers for Domino, Simple Mail Users is added as a
performance measurement.
Note 2: Processor performance represents the relative performance (maximum capacity) of a processor feature
running CPW in a client/server environment. Processor capacity is achievable when the commercial workload
is not constrained by main storage and DASD. Interactive Performance represents the relative performance
available to perform host-centric workloads. The amount of interactive capacity consumed reduces the
available processor capacity by the same amount. On the Dedicated Servers for Domino, the Processor CPW
is an approximate value reflecting the maximum amount of non-Domino workload (10 to 15% of CPU) that can
be supported.
Note 3: The total number of tape drives does not increase.
