hopper
of
the
loading
unit
(2501
in
the
example)
•
4.
Place
card
group
090
(job
control
cards)
into
the
hopper
of
SYSRDR
(2501
in
the
ex
ample)
•
5.
Place
card
group
091
(sample
source
progra~
into
the
hopper
of
SYSIPT
(2501
in
the
example).
Press
·the
start
key
of
the
device.
6.
Place
blank
cards
into
the
hopper
of
SYSOPT
(2560
secondary
feed
in
the
example)
and
press
the
Start
key
of
the
device.
7.
Install
forms
in
the
printer
(1403
in
the
example)
and
press
the
Reset
key
and
the
start
key
of
the
device.
8.
Set
the
Register-Data/Address
switches
on
the
CPU
console
to
an
even
core
storage
address
between
hexadecimal
009C
and
the
end-of-storage
address
minus
hexadecimal
0052.
9.
Set
the
Mode
switch
on
the
CPU
console
to
PROCESS.
10.
Press
the
Load
key
on
the
CPU
console.
A
sample
of
the
Assembler
listing
obtained
on
the
printer
is
shown
in
Figure
25.
The
object
program,
contained
in
punched
cards,
is
obtained
on
SYSOPT.
The
system
then
halts
and
.code
01DO
is
displayed.
The
execution
of
the
sample
program
reguires
a
tape
on
the
drive
assigned
SYS001
(see
ASSGN
card
in
group
092)
•
tape
must
contain
a
volume
label
with
volume
serial
number
000001.
to
This
the
The
following
steps
must
be
taken
to
write
this
label
on
tape
by
means
of
the
Initialize-Tape
Utility
program.
1.
The
system
tape
(containing
the
Initialize-Tape
Utility
program)
remains
on
the
tape
drive
assigned
to
SYSRES
from
the
previous
run.
2.
The
tape
on
the
drive
assigned
to
SYS-
000
(see
ASSGN
card
in
group
097)
is
already
positioned
at
the
load
point
from
the
previous
run.
3.
Place
the
tape
IPL
deck
(containing
ASSGN
cards
for
SYSRES
and
SYSRDR
from
the
previous
ru~
into
the
hopfer
of
the
loading
unit
(2501
in
the
example).
4.
Place
group
097
(job
control
state-
ments)
and
card
group
098
(program
con-
trol
statements)
into
the
hopper
of
SYSRDE
(2501
in
the
example),
and
press
the
start
key
of
the
device.
5.
set
the
Register-Data/Address
switches
on
the
CPU
console
to
an
even
main
storage
address
between
hexadecimal
009C
and
the
end-of-storage
address
minus
hexadecimal
0052.
6.
set
the
Mode
switch
on
the
CPU
console
to
PRO
CISS.
7.
Press
the
Load
key
on
the
CPU
console.
After
the
volume
label
has
been
written
onto
tape,
the
system
halts
and
code
01DO
is
displayed.
1he
following
steps
must
be
taken
to
execute
the
object
program
obtained
as
card
output
from
the
Assembler
under
control
of
the
card-resident
system.
1.
Place
the
card
IPL
deck
into
the
hopper
of
the
loading
unit
(2501
in
the
example)
•
2.
Prepare
the
appropriate
ASSGN
card
for
SYSRDR
and
place
it
behind
the
IPL
deck.
3.
Place
the
card
Basic
Monitor
deck
into
the
hopper
of
the
loading
unit.
4.
Place
the
following
cards
into
the
hop-
per
of
SYSRr:R:
5.
•
phases
00,
01
and
02
of
the
Job
Con-
trol
program
deck,
•
card
group
092
(job
control
cards)
,
and
•
phase
03
of
the
Job
Control
program.
Place
the
sample
object
deck
into
the
hopper
of
SYSRDR.
6.
Press
the
start
keyes)
of
the
card
reading
device{s)
used.
7.
Press
the
Reset
key
and
the
Start
key
of
the
printer.
8.
The
initialized
tape
is
mounted
on
the
tape
drive
assigned
to
SYS001
(see
ASSGN
card
in
group
092)
and
positioned
at
the
load
point,
from
the
previous
run.
9.
Set
the
Register-Data/Address
switches
on
the
CPU
console
to
an
even
main
storage
address
between
hexadecimal
009C
and
the
end-of-storage
address
minus
hexadecimal
0052.
76
System/360
Model
20 TPS
Operating
Procedures
